Specs
- Input Voltage: 10-30V DC
- Wattage: 18W (6-3W OSRAM LEDs)
- Raw Lumens: 1440
- Color Temperature: 6000K
- Beam Pattern: 8deg Spot
Construction
- Housing Material: Die-cast Aluminum Housing
- Housing Color: Black
- Membrane: Gore™
- Lens Material: PC
- Mounting Bracket: Black Powder Coated Steel
- Hole Dimensions: Mounting Bolt Drill – .25"
- Electronics: Integrated-Epoxy Encapsulated
- Hardware: Stainless 316
Operation
- Operating Temperature: -40degC to +60degC
- Current Consumption: .9 amps at 13.8 volts
- IP Rating: IP67
- Protections: Reverse Polarity
